This machine can be widely used for outdoor garden or restaurant cooling, vegetable freshing, greenhouse irrigation, stockbreeding cooling, summer fly remove and so on, it can reduce the outside weather temperature from 5℃ to 10℃, and also will highly increase the humidity, it's a new type of outdoor air conditioner.
3/8"(9.52mm) 80bar High Pressure Nylon PA 12 Pipe for Misting System
Our advantage
With 5 years investment and development, FG Machine now have the world newest low pressure fog misting nozzle (Misting system), it's equipped with newest 3 pistons pump and new design motor, and also with very modern & advanced operation system, People can enjoy the amazing low noise, beautiful looking and high mist spray performance. This machine can be widely used for outdoor garden or restaurant cooling, vegetable freshing, greenhouse irrigation, stockbreeding cooling, summer fly remove and so on, it can reduce the outside weather temperature from 5℃ to 10℃, and also will highly increase the humidity, it's a new type of outdoor air conditioner.
Detail specification:
| Product | Description | Size | |
| 1 | stainless steel pipe | 1,304 SS Seamless or seam pipe | 3/8” (9.52mm) 1/4”(6.35mm) |
| 2,Working pressure>250Bar | |||
| 3,With Chamfer, groove, polishing | |||
| 2 | Nylon PA12 | 1,Max working pressure: 100Bar | |
| 2,work at -40℃ ~ 120℃ | |||
| 3,Soft pipe, easy installation | |||
|
4,6 & 11. Double life & double anti ageing ability than PA6 or PA11 |
|||
| 3 | 6 & 11 Nylon PA6 & PA11 |
1,Max working pressure: 110Bar | |
| 2,work at -30℃ ~ 80℃ | |||
| 3, Hard pipe, good working pressure | |||
| 4 | PE | 1,Max working pressure: 90Bar | |
| 2,work at -30℃ ~ 80℃ | |||
| 3,Cheap Price | |||
| 5 | SS ring | Size and nozzle quantity can be special made |
| A.Average Life: SS > PA12 > PA11 = PA6 > PE |
| B.Pressure ability SS > PA12 > PA11 = PA6 > PE |
| C.High temperature & low temperature ability: SS > PA12 > PA11 > PA6 > PE |
| D.Anti-aging under the sunshine: SS > PE > PA12 > PA11 > PA6 |
| E.Anti-aging without the sunshine: SS > PA12 =PE > PA11 > PA6 |
| F.Material Price: SS > PA12 > PA11 = PA6 > PE |
| G.Hardness: SS > PE > PA11 = PA6 > PA12 (PA12 is soft pipe) |
| General performance: : SS > PA12 > PA11 = PA6 > PE |
