-ADVANCED TECHNOLOGY:
5 to 10 years ahead of competitors.The FG-050S even can:
A.Pressure can be adjusted by touch or remote
B.Water flow will be adjusted automatically
-VERY SAFE、VERY HUMANIZED
VERY SAFE: Electrical leakage + water lack + overwork+ overheat protection
VERY HUMANIZED: Anti drip + constant pressure + maintain warning+
warranty time reminder system
-ADVANCED OPERATION SYSTEM
Automatic sensor and remote system
-CORROSION RESISTANCE
-EASY INSTALLATION
| Taizhou Fog Machine: 7 Models Specs. | |||||||||
| Model | Water flow | Pump | Pressure | Power | Motor Rpm | Noise | Maintainstime | Remote | Cooling size |
| FG-025 | 0.25L/min | 3 pistons | 70Bar | 90W | 600 | 48db | 2000h | Yes | 3 - 20M2 |
| FG-050 | 0.5L/min | 3 pistons | 70Bar | 150W | 1100 | 50db | 1000h | Yes | 5 - 35M2 |
| FG-050S | 0.2~0.7L/min(automatic) | 3 pistons | 70Bar | 150W | 500~1500 automatic | 48db | 1000-2000h | Yes | 3 - 45M2 |
| FG-100 | 50Hz: 1.0L/Min 60Hz: 1.2L/min | 3 pistons | 70Bar | 180W | 1400/50Hz 1680/60Hz | 56db | 800-1200h |
Yes
|
10 - 65M2 |
| FG-150 | 50Hz: 1.5L/Min 60Hz: 1.8L/min | 3 pistons | 70Bar | 180W | 1400/50Hz 1680/60Hz | 56db | 800-1200h | Yes | 20 -100M2 |
| FG-200 | 50Hz: 2.0L/Min 60Hz: 2.4L/min | 3 pistons | 70Bar | 250W | 1400/50Hz 1680/60Hz | 58db | 800-1200h | Yes | 30 - 150M2 |
| FG-300 | 3.0L/min | 3 pistons | 70Bar | 750W | 1700 | 60db | 800-1200h | Yes | 50 - 200M2 |
| Number of Nozzles Carried By 7 Models | ||||||
| Model | FaimilyVoltage | MotorVoltage |
Flow rate L/min
|
Nozzle pieces | Nozzle pieces | Nozzle pieces |
| orifice:0.1mm | orifice:0.15mm | orifice:0.20mm | ||||
|
FG-025
|
110/220V 50-60HZ | 12V DC | 0.25 | 2~8 | 2~6 | 2~4 |
| FG-050 | 110/220V 50-60HZ | 12V DC | 0.5 |
5~14
|
5~12 | 3~7 |
| FG-050S | 110/220V 50-60HZ | 12V DC | 0.2~0.7 | 2~18 | 2~16 | 2~10 |
| FG-100 | 220V/50HZ | 220V AC | 1 | 12~30 | 8~25 | 6~15 |
| FG-150 | 220V/50HZ | 220V AC | 1.5 | 18~45 | 12~35 | 8~22 |
| FG-200 | 220V/50HZ | 220V AC | 2 | 24~60 | 20~50 | 12~30 |
| FG-100 | 110/220V 60HZ | 110/220V AC | 1.2 | 12~35 | 8~28 | 7~18 |
| FG-150 | 110/220V 60HZ | 110/220V AC | 1.8 | 20~50 | 12~40 | 10~27 |
| FG-200 | 220V 60HZ | 220V AC | 2.4 | 28~65 | 22~60 | 15~36 |
| FG-300 | 110/220V 60HZ | 311V DC | 3 | 60~90 | 50~75 | 35~50 |
